DETAILS
Technical Parameters:
| Blade Material | Imported alloy steel |
| Production Efficiency | 2s (depending on stripping length) |
| Cutting Wire Diameter Range | 10–30mm |
| Stripping Length Range | 0–150mm |
| Max Number of Stripping Layers | 9 layers |
| Minimum Stripping Accuracy | 0.01mm |
| Number of Blades | 4 PCS |
| Stripping Method | Rotary |
| Drive Mode | Electric drive |
| Power Supply | AC220V HZ50–60 |
| Air Source | Not required |
| Start Method | Button or foot pedal |
| Dimensions | 955 × 265 × 440mm |
| Weight | 50.2kg |
| Applicable Wire Types | Single conductor wires, insulated cables, coaxial cables, solid wires, shielded cables, concentric types, etc. |
